The VEGABAR 82 is a highly accurate, all-round pressure transmitter equipped with a robust ceramic CERTEC® measuring cell. Designed for demanding industrial and marine environments, it delivers precise and long-term stable pressure measurements in tanks, pipelines, and shipboard systems — even in the presence of aggressive or abrasive media.
The VEGABAR 82 is a universal process pressure transmitter developed to measure gases, vapors, and liquids under varying conditions. Its core strength lies in the ceramic CERTEC® measuring cell, which offers excellent chemical resistance, high overload capability, and long-term reliability — even in harsh conditions such as on ships, in offshore installations, or within processing plants.
In maritime applications, the VEGABAR 82 is widely used for monitoring pressure in ballast water tanks, cargo tanks, service tanks, manifolds, and hydraulic systems. Its compact and rugged design allows it to perform accurately despite vibration, temperature fluctuations, and exposure to seawater or corrosive chemicals.
The transmitter provides consistent, drift-free measurement even during pressure shocks or rapid temperature changes. Its front-flush sensor design supports optimal cleaning and reduces the risk of buildup in pipelines or tanks. The VEGABAR 82 can also be used in electronic differential pressure configurations by combining two sensors — ideal for monitoring filters, pump pressure, or closed vessel levels.
Marine Technic supplies the VEGABAR 82 to shipyards, fleet operators, and offshore contractors seeking dependable pressure sensors. With in-depth knowledge of VEGA instrumentation and marine environments, we ensure reliable solutions and expert support for every project.
Pressure Range: -1 to +100 bar
Process Temperature: -40 °C to +150 °C
Accuracy: ±0.05%
Measuring Cell: Ceramic CERTEC®, oil-free, overload-resistant
Wetted Materials: PVDF, 316L, Duplex 1.4462, Titanium Grade 2, Alloy C22, Alloy C276, PP
Process Connections: Threaded ≥ G¼ / ¼” NPT, Flanged ≥ DN15 / ½”, hygienic fittings available
Output Options: 4–20 mA, HART, Profibus PA, Foundation Fieldbus, Modbus
Protection Class: IP66 / IP68 / IP69K
Installation: Direct mounting in tanks or pipelines, front-flush or standard fitting
Marine Applications: Ballast water tanks, manifolds, pump systems, hydraulic pressure monitoring
Compliance: Suitable for marine classification, SIL2-certified, shock and vibration tested
